Gavere FEQ

Poids 13.4 kg
Cadre Aluminium 6061
Taille 48, 51, 54, 56, 58, 61 cm
Color Stealth Black

Prix

Prix public conseillé
690 800,00 Ft

Gravel all-rounder & year-round commuter

The Gavere FEQ is the everyday racer for fast commutes, after-work gravel rides or bikepacking adventures. The elegant aluminium frame in STEVENS Stealth Black with a lightweight aluminium fork ensures smooth running and comfort thanks to its relaxed geometry. Robust gravel wheels with 40 mm Schwalbe G-One Overland tyres offer grip and control on asphalt, gravel and off-road. Shimano CUES 2x10 gears and Tektro disc brakes guarantee reliable riding. The FEQ version impresses with its extensive everyday equipment, including a rear rack and hub dynamo LED lights, as well as versatile packing options for weekend tours.

  • FEQ everyday racer based on the Gavere Gravel Alloy bikes
  • Shimano CUES U6000 2x10-speed gear system with Tektro disc brakes
  • High-quality LED lighting system from Busch & Müller, lightweight mudguards and practical rear rack
  • Wide range of sizes with six frame heights
  • 40 mm wide Schwalbe G-One Overland tyres

Équipement

Détails

Les images peuvent différer. Sous réserve de modifications de l'équipement.

Châssis

Cadre
Aluminium 6061
  • O.L.D.: 142 mm
  • Brake: flatmount disc
  • BB: Pressfit BSA68
  • Front derailleur mount: clamp
  • Cable routing: internal
  • Fender + rack mounts
Fourche
STEVENS S-Lite Aluminium
  • Tapered Steerer 1 1/8" - 1.5"
  • O.L.D.: 100 mm
  • Brake: flatmount disc
Jeu de direction
Token TK1556PD
  • Upper bearing cup: IS52/28.6
  • Lower bearing cup: IS52/40
Frein avant
Tektro MD-C550
  • Mechanical disc brake
  • 2 pistons
Frein arrière
Tektro MD-C550
  • Mechanical disc brake
  • 2 pistons
Disque de frein
Tektro TR160-35
  • Rotor size: 160 mm
  • Center-Lock

Transmission

Pédalier
Shimano CUES U6000
  • Shimano FC-U6030-2
  • 46-32 T
  • Hollowtech II
  • BB type: BSA 68 mm
Dérailleur avant
Shimano CUES U6000
  • FD-U6030-F
  • 2-speed
Dérailleur arrière
Shimano CUES U6000 Shadow
  • RD-U6020-10-SGS
  • 10-speed
  • Total capacity: 44 T
Chaîne
Shimano CN-LG500
  • LINKGLIDE
Cassette
Shimano CS-LG300-10
  • 10-speed
  • Combination: 11-13-15-17-20-23-26-30-34-39 T
Pédales
ATB Pedal Reflex

Roues

Moyeu arrière
Formula RXC-400
  • Axle: QR12x142 mm
Moyeu avant
Shutter Precision PL-7
  • Hub dynamo
  • Axle: QR12x100 mm
Jantes
Oxygen G25 Disc
  • ETRTO: 25 x 622
Pneus
Schwalbe G-One Overland Performance
  • Tire size: 40-622
  • Foldable
  • RaceGuard
  • ADDIX Eco
  • Tubeless Easy
  • Reflective stripes

Poste de pilotage

Cintre
Scorpo Aero Gravel
  • Drop: 130 mm
  • Reach: 70 mm
  • Flare: 16°
  • Rise: 10 mm
  • Clamp: 31.8 mm
Potence
Scorpo
  • Handlebar clamp: 31.8 mm
  • Angle: -6°
Selle
Oxygen Triton 2.0
Tige de Selle
Scorpo
  • Length: 350 mm
  • Diameter: 27.2 mm
  • Insertion depth: min. 100 mm
Levier de commande gauche
Shimano CUES
  • ST-U3030
  • 2-speed
Levier de commande droite
Shimano CUES
  • ST-U3030
  • 10-speed
Feu avant
Trelock Light Hammer 60
  • Illuminance: 60 lux
Feu arrière
B+M Xeltec Mini
  • Stationary taillight
Porte-Bagages
Racktime STV RC 07
  • System: SNAP IT 2.0
  • QL3.1 Mounting system
Gardes-boue
Curana Apollo 55
Béquille
STEVENS Edge
  • Kickstand mount: KSA 40
Cloche
STEVENS D85 bell

Données

Poids
13.4 kg
Poid en charge max.
130 kg
Couleur (s)
Stealth Black
Taille
48, 51, 54, 56, 58, 61 cm


Gravel forks.

The new STEVENS Gavere model series is based on a completely new aluminium frame, which is combined with a full carbon SL fork or a STEVENS S-Lite fork, depending on the model.

Advantages of a STEVENS full carbon fork:

Lightweight and robust: The latest developments in carbon technology set new standards – full carbon forks are robust and significantly lighter than aluminium forks.
Stiff: Carbon is lightweight, stiff and resilient. Its high stiffness ensures direct steering response and improves handling and precision.
Comfortable: They absorb vibrations and shocks on trails and gravel paths and provide noticeably more comfort on long rides.

Advantages of a STEVENS S-Lite aluminium fork:

Robust and durable: Aluminium and carbon forks have a comparable service life.
Budget-friendly: Aluminium is high-quality, durable and attractively priced.

One Bike – countless possibilities.

Anyone travelling by bike needs storage space. That's why our designers in Hamburg are constantly developing clever solutions to tailor our gravel bikes perfectly to the needs of bike packers.

All Gavere gravel bikes have numerous mounting options:

Up to three bottle holders
Storage box or ‘bento bag’ on the top tube
Mounts on the fork
Mudguards

This creates a wide variety of options for attaching luggage and equipment – while maintaining high riding stability, even when fully loaded and at high speeds. Thanks to the threaded eyelets on the frame and fork, panniers can be attached easily, quickly and securely.

FEQ – Fully Equipped for fast commuters.

Gavere gravel bikes bridge the gap between rough terrain and smooth city streets. This makes them the ideal choice for fast laps on mixed terrain, carefree commuting on gravel paths, cycle paths and asphalt, or uncomplicated adventure tours in your free time.

The FEQ (Fully EQuipped) versions also feature a sturdy, stylish rear rack for attaching bags on both sides of the bike, high-quality hub dynamo lighting at the front and rear, sturdy mudguards with a neutral look, and a robust side stand.

The fully equipped Gavere is available as:

Gavere Pro FEQ
Gavere Com FEQ
Gavere FEQ

More room for adventure.

With STEVENS gravel bikes, generous tyre clearance – i.e. the distance between the tyres, fork and rear triangle – is a basic requirement.

Tyre width directly influences comfort, traction and handling. Wide tyres allow you to ride with lower air pressure, providing greater comfort – especially on longer distances over uneven surfaces. The larger contact area generates more traction, which is an advantage on rough or muddy trails – even when sticky mud and clay clog the tyre tread. At the same time, gravel tyres still roll easily and with low vibration on paved roads. For maximum riding enjoyment and high riding safety – no matter what the conditions.

Without mudguards, the Gavere can be ridden with tyres up to 50 mm wide (with mudguards, the maximum tyre clearance is 45 mm).

Intuitive gravel group.

The top-of-the-range Gavere models – the Gavere Pro and Gavere Pro FEQ – are equipped with the electronic wireless SRAM Apex AXS 1x12 groupset.

Apex is SRAM's first pure gravel groupset. With its XPLR rear derailleur, it offers a wide gear range: one chainring at the front and 12 gears – perfect for gravel, bikepacking, adventure, touring and everything in between. The 1x12 setup ensures that you always have the right gear for every situation.

The AXS version – the wireless, electronic variant – enables precise, smooth and reliable shifting for the best possible riding experience. It is intuitive to understand and easy to use, allowing you to concentrate fully on riding.

Carefully selected components ensure harmonious function, long service life and exceptional, sporty riding pleasure. This applies not only to the Gavere, but to all STEVENS bikes.

Building bridges.

Named after the famous cross-country race in the Belgian municipality, the Gavere reflects STEVENS' close connection to the cycling discipline of cyclocross. Our experience with fast off-road drop bar bikes also flows into our award-winning gravel bikes.

Combined with our many years of experience and expertise in frame geometry and high-quality engineering, the result is durable, timelessly elegant bikes. For riding pleasure on the way to work as well as on small or big adventures (not only) at the weekend.

Find our complete Gravel Bike range here.

Géométrie

schematische Skizze eines Fahrrades mit eingezeichneten Geometrie-Messpunkten

Le conseil en ligne sur les tailles ne remplace pas le conseil d'un revendeur spécialisé. Il sert à une première orientation et peut différer des préférences personnelles. Un essai sur route offre la meilleure comparaison.

Taille cadre (cm)   48 51 54 56 58 61 Type de mesure
Hauteur tube de selle A1 570 594 619 638 660 680 nominal
Hauteur tube de selle A2 450 480 510 540 570 600 Centre de l'axe de pédalier jusqu'au tube de selle
Hauteur tube de selle A3 411 441 470 500 530 560 Centre de l'axe de pédalier jusqu'au tube horizontal
Longueur tube horizontal B 504 531 553 569 584 600
Longueur tube horizontal C 516 551 576 591 606 621 jusqu'à la tige de selle
Angle tube de direction (°) D 70 71 71,5 71,5 72 72
Angle tube de selle (°) E 76 74 73 73 73 73
Empattement F 1036 1042 1052 1067 1077 1093
Longueur tube des bases G 440 440 440 440 440 440
Longueur tube de direction H 115 130 150 170 190 210
Abaissement axe pédalier I 70 70 70 70 70 70 Distance de l'axe de pédalier au moyeu
Hauteur pédalier K 284 284 284 284 284 284 Distance au sol
Courbure du cintre L 45 45 45 45 45 45
Slope M 151 143 137 128 120 110 Tube horizontal: différence de niveau avant/arrière
Radius roue avant N1 353,5 353,5 353,5 353,5 353,5 353,5 tyred
Radius roue arrière N2 353,5 353,5 353,5 353,5 353,5 353,5 tyred
Hauteur cadre O 742 767 792 816 842 866 distance dessus du tube horizontal – sol
Top tube height O1 458 483 509 533 558 583 standover height minus bottom bracket height
Hauteur de la fourche P 414 414 414 414 414 414 Capots de jeu de direction compris
Distance roue avant – axe pédalier Q 606 611 621 637 647 662
Reach R 378 387 395 404 413 422 Du boitier de pédalier au tube de direction, horizontalement
Stack S 553 571 592 611 632 651 Du boitier de pédalier au tube de direction, verticalement
Stack/Reach (1:x)   1,46 1,48 1,5 1,51 1,53 1,54 Rapport entre Stack et Reach
Diamètre tige de selle   27,2 27,2 27,2 27,2 27,2 27,2
Longueur potence   70 70 70 80 90 100 Centre-Centre
Angle potence (°)   -6 -6 -6 -6 -6 -6
Collier de potence   31,8 31,8 31,8 31,8 31,8 31,8
Entretoises montées   8 + 2*5 + 3*10
Largeur cintre   420 420 420 440 440 440
Longueur manivelle   170 170 172,5 172,5 175 175
    48 51 54 56 58 61

* measured 100 mm ahead of bottom bracket
