Gavere FEQ

Gewicht	13.4 kg
Frame	Aluminium 6061
Maten	48, 51, 54, 56, 58, 61 cm
Color	Stealth Black

Prijzen

Adviesprijs: 690 800,00 Ft

Gravel all-rounder & year-round commuter

The Gavere FEQ is the everyday racer for fast commutes, after-work gravel rides or bikepacking adventures. The elegant aluminium frame in STEVENS Stealth Black with a lightweight aluminium fork ensures smooth running and comfort thanks to its relaxed geometry. Robust gravel wheels with 40 mm Schwalbe G-One Overland tyres offer grip and control on asphalt, gravel and off-road. Shimano CUES 2x10 gears and Tektro disc brakes guarantee reliable riding. The FEQ version impresses with its extensive everyday equipment, including a rear rack and hub dynamo LED lights, as well as versatile packing options for weekend tours.

FEQ everyday racer based on the Gavere Gravel Alloy bikes
Shimano CUES U6000 2x10-speed gear system with Tektro disc brakes
High-quality LED lighting system from Busch & Müller, lightweight mudguards and practical rear rack
Wide range of sizes with six frame heights
40 mm wide Schwalbe G-One Overland tyres

Foto's kunnen afwijken. Uitrusting onderhevig aan verandering.

Chassis

Frame

Aluminium 6061

O.L.D.: 142 mm
Brake: flatmount disc
BB: Pressfit BSA68
Front derailleur mount: clamp
Cable routing: internal
Fender + rack mounts

Voorvork

STEVENS S-Lite Aluminium

Tapered Steerer 1 1/8" - 1.5"
O.L.D.: 100 mm
Brake: flatmount disc

Balhoofd

Token TK1556PD

Upper bearing cup: IS52/28.6
Lower bearing cup: IS52/40

Voorrem

Tektro MD-C550

Mechanical disc brake
2 pistons

Achterrem

Tektro MD-C550

Mechanical disc brake
2 pistons

Remschijf

Tektro TR160-35

Rotor size: 160 mm
Center-Lock

Aandrijflijn

Crankstel

Shimano CUES U6000

Shimano FC-U6030-2
46-32 T
Hollowtech II
BB type: BSA 68 mm

Voorderailleur

Shimano CUES U6000

FD-U6030-F
2-speed

Achterderailleur

Shimano CUES U6000 Shadow

RD-U6020-10-SGS
10-speed
Total capacity: 44 T

Ketting

Shimano CN-LG500

LINKGLIDE

Cassette

Shimano CS-LG300-10

10-speed
Combination: 11-13-15-17-20-23-26-30-34-39 T

Pedalen: ATB Pedal Reflex

Wielen

Naaf achter

Formula RXC-400

Axle: QR12x142 mm

Naaf voor

Shutter Precision PL-7

Hub dynamo
Axle: QR12x100 mm

Velgen

Oxygen G25 Disc

ETRTO: 25 x 622

Banden

Schwalbe G-One Overland Performance

Tire size: 40-622
Foldable
RaceGuard
ADDIX Eco
Tubeless Easy
Reflective stripes

Cockpit

Stuur

Scorpo Aero Gravel

Drop: 130 mm
Reach: 70 mm
Flare: 16°
Rise: 10 mm
Clamp: 31.8 mm

Stuurpen

Scorpo

Handlebar clamp: 31.8 mm
Angle: -6°

Zadel: Oxygen Triton 2.0

Zadelpen

Scorpo

Length: 350 mm
Diameter: 27.2 mm
Insertion depth: min. 100 mm

Versnellingshendel links

Shimano CUES

ST-U3030
2-speed

Versnellingshendel rechts

Shimano CUES

ST-U3030
10-speed

Koplamp

Trelock Light Hammer 60

Illuminance: 60 lux

Achterlicht

B+M Xeltec Mini

Stationary taillight

Bagagedrager

Racktime STV RC 07

System: SNAP IT 2.0
QL3.1 Mounting system

Spatborden: Curana Apollo 55

Kickstand

STEVENS Edge

Kickstand mount: KSA 40

Bel: STEVENS D85 bell

Gegevens

Gewicht: 13.4 kg

Toegest. totaalgewicht: 130 kg

Kleur(en): Stealth Black

Maten: 48, 51, 54, 56, 58, 61 cm

Gravel forks.

The new STEVENS Gavere model series is based on a completely new aluminium frame, which is combined with a full carbon SL fork or a STEVENS S-Lite fork, depending on the model.

Advantages of a STEVENS full carbon fork:

Lightweight and robust: The latest developments in carbon technology set new standards – full carbon forks are robust and significantly lighter than aluminium forks.
Stiff: Carbon is lightweight, stiff and resilient. Its high stiffness ensures direct steering response and improves handling and precision.
Comfortable: They absorb vibrations and shocks on trails and gravel paths and provide noticeably more comfort on long rides.

Advantages of a STEVENS S-Lite aluminium fork:

Robust and durable: Aluminium and carbon forks have a comparable service life.
Budget-friendly: Aluminium is high-quality, durable and attractively priced.

One Bike – countless possibilities.

Anyone travelling by bike needs storage space. That's why our designers in Hamburg are constantly developing clever solutions to tailor our gravel bikes perfectly to the needs of bike packers.

All Gavere gravel bikes have numerous mounting options:

Up to three bottle holders
Storage box or ‘bento bag’ on the top tube
Mounts on the fork
Mudguards

This creates a wide variety of options for attaching luggage and equipment – while maintaining high riding stability, even when fully loaded and at high speeds. Thanks to the threaded eyelets on the frame and fork, panniers can be attached easily, quickly and securely.

FEQ – Fully Equipped for fast commuters.

Gavere gravel bikes bridge the gap between rough terrain and smooth city streets. This makes them the ideal choice for fast laps on mixed terrain, carefree commuting on gravel paths, cycle paths and asphalt, or uncomplicated adventure tours in your free time.

The FEQ (Fully EQuipped) versions also feature a sturdy, stylish rear rack for attaching bags on both sides of the bike, high-quality hub dynamo lighting at the front and rear, sturdy mudguards with a neutral look, and a robust side stand.

The fully equipped Gavere is available as:

Gavere Pro FEQ
Gavere Com FEQ
Gavere FEQ

More room for adventure.

With STEVENS gravel bikes, generous tyre clearance – i.e. the distance between the tyres, fork and rear triangle – is a basic requirement.

Tyre width directly influences comfort, traction and handling. Wide tyres allow you to ride with lower air pressure, providing greater comfort – especially on longer distances over uneven surfaces. The larger contact area generates more traction, which is an advantage on rough or muddy trails – even when sticky mud and clay clog the tyre tread. At the same time, gravel tyres still roll easily and with low vibration on paved roads. For maximum riding enjoyment and high riding safety – no matter what the conditions.

Without mudguards, the Gavere can be ridden with tyres up to 50 mm wide (with mudguards, the maximum tyre clearance is 45 mm).

Intuitive gravel group.

The top-of-the-range Gavere models – the Gavere Pro and Gavere Pro FEQ – are equipped with the electronic wireless SRAM Apex AXS 1x12 groupset.

Apex is SRAM's first pure gravel groupset. With its XPLR rear derailleur, it offers a wide gear range: one chainring at the front and 12 gears – perfect for gravel, bikepacking, adventure, touring and everything in between. The 1x12 setup ensures that you always have the right gear for every situation.

The AXS version – the wireless, electronic variant – enables precise, smooth and reliable shifting for the best possible riding experience. It is intuitive to understand and easy to use, allowing you to concentrate fully on riding.

Carefully selected components ensure harmonious function, long service life and exceptional, sporty riding pleasure. This applies not only to the Gavere, but to all STEVENS bikes.

Building bridges.

Named after the famous cross-country race in the Belgian municipality, the Gavere reflects STEVENS' close connection to the cycling discipline of cyclocross. Our experience with fast off-road drop bar bikes also flows into our award-winning gravel bikes.

Combined with our many years of experience and expertise in frame geometry and high-quality engineering, the result is durable, timelessly elegant bikes. For riding pleasure on the way to work as well as on small or big adventures (not only) at the weekend.

Find our complete Gravel Bike range here.

Geometrie

schematische Skizze eines Fahrrades mit eingezeichneten Geometrie-Messpunkten

Het online maatadvies is geen vervanging voor het advies van een speciaalzaak. Het dient als een eerste oriëntatie en kan afwijken van persoonlijke voorkeuren. Een proefrit biedt de beste vergelijking.

Framemaat (cm)		48	51	54	56	58	61	Meetmethode
Zitbuislengte	A1	570	594	619	638	660	680	Nominaal
Zitbuislengte	A2	450	480	510	540	570	600	Hart trapas tot bovenkant zitbuis
Zitbuislengte	A3	411	441	470	500	530	560	Hart trapas tot bovenkant bovenbuis
Bovenbuislengte	B	504	531	553	569	584	600
Bovenbuis horizontaal	C	516	551	576	591	606	621	Tot snijpunt zadelpen
Hoek van de balhoofdbuis (°)	D	70	71	71,5	71,5	72	72
Zitbuishoek (°)	E	76	74	73	73	73	73
Wielbasis	F	1036	1042	1052	1067	1077	1093
Lengte van de liggende achtervork	G	440	440	440	440	440	440
Lengte van de balhoofdbuis	H	115	130	150	170	190	210
Trapasverlaging	I	70	70	70	70	70	70	Afstand tot naafhoogte
Trapashoogte	K	284	284	284	284	284	284	Afstand tot grond
Vorksprong	L	45	45	45	45	45	45
Sloping	M	151	143	137	128	120	110	Hoogteverschil bovenbuis voor/achter
Radius fietswiel voorzijde	N1	353,5	353,5	353,5	353,5	353,5	353,5	tyred
Radius fietswiel achterzijde	N2	353,5	353,5	353,5	353,5	353,5	353,5	tyred
Standoverhoogte	O	742	767	792	816	842	866	Bovenkant bovenbuis tot grond*
Top tube height	O1	458	483	509	533	558	583	standover height minus bottom bracket height
Inbouwhoogte van de voorvork	P	414	414	414	414	414	414	Incl. de onderste balhoofdcup
Afstand voorwiel tot trapas	Q	606	611	621	637	647	662
Reach	R	378	387	395	404	413	422	Horizontaal van trapas tot balhoofdbuis
Stack	S	553	571	592	611	632	651	Verticaal van trapas tot balhoofdbuis
Stack/reach (1:x)		1,46	1,48	1,5	1,51	1,53	1,54	Verhouding stack tot reach
Diameter van de zadelpen		27,2	27,2	27,2	27,2	27,2	27,2
Stuurpenlengte		70	70	70	80	90	100	Hart op hart
Stuurpenhoek (°)		-6	-6	-6	-6	-6	-6
Stuurklem		31,8	31,8	31,8	31,8	31,8	31,8
Gemonteerde spacers		8 + 25 + 310
Stuurbreedte		420	420	420	440	440	440
Cranklengte		170	170	172,5	172,5	175	175
		48	51	54	56	58	61

* measured 100 mm ahead of bottom bracket

Bike-Category 4

Cross and gravel bikes

This category describes STEVENS cross and gravel bikes. They have 28” - inch wheels with narrow tyres. The tyre width is 28 to max. 42 mm. STEVENS ALLROUND X Cross, STEVENS Gravel.

Instructions on intended use

The maximum permissible overall weight (comprising rider, luggage, possibly trailer load and bicycle) should not exceed 130 kg. Under certain circumstances the permissible maximum weight can be further limited by the component manufacturers’ recommendations for use or weight limits. You find more information in the instructions od on the website of the respective component manufacturers.
STEVENS cross and gravel bikes are designed for a trailer load of 40 kg without and 80 kg with trailer brake. On STEVENS gravel bikes made of carbon, however, the use of trailers is not permitted.
On STEVENS cross and gravel bikes made of carbon child seats are not permitted. On STEVENS cross and gravel bikes made of aluminium child seats are permitted. For more information see the chapter “Use of Child Seats” in your comprehensive STEVENS user manual.

STEVENS cross bikes are intended for hard-surface terrain, i.e. for tarred roads and bicycle lanes or gravel field tracks, where the wheels do not lose ground contact. In addition, they are well suited for well paved gravel paths and forest roads as well as off-road trails with a slight slope where a temporary loss of tyre contact with the ground due to small steps may occur. They are not suitable for off-road use (mountain bike use), namely for all mountain, enduro, downhill (DH), freeride, dual slalom, downhill/freeride parks, jumps, drops and in bike parks etc.

Due to their design and fittings, STEVENS cross bikes are not always suitable for being used on public roads. If you want to use them on public roads, these bikes must be fitted with the prescribed equipment. Observe the traffic rules when riding on public roads. For more information read the chapter “Legal Requirements for Riding on Public Roads” in your comprehensive STEVENS user manual on our website www.stevensbikes.de/manual.

Danger:

STEVENS bicycles of the category 4 are not suitable for off-road use, jumps, slides, stair riding, stoppies, wheelies, tricks etc.!

	Stealth Black
48 cm	126451402
51 cm	126451405
54 cm	126451408
56 cm	126451410
58 cm	126451412
61 cm	126451415
